Deye BOS‑A 7.68kWh HV Battery Module (high-voltage battery module)

Description Product Description The BOS-A 7.68kWh battery module is engineered to provide safe, efficient, and long-lasting energy storage for hybrid and off-grid solar systems. Built with advanced LiFePO₄ cell technology, it delivers enhanced thermal stability, deep discharge capability, and extended service life. The modular design allows multiple units to be connected in parallel for increased storage capacity, making it suitable for both small residential installations and larger commercial energy systems. An integrated Battery Management System (BMS) ensures protection against overcharge, over-discharge, overcurrent, and temperature fluctuations. The BOS-A 7.68kWh is ideal for load shifting, backup power, self-consumption optimization, and energy cost reduction in areas with unstable grid supply. Technical Specifications Battery Specifications Nominal Energy: 7.68 kWh Battery Chemistry: Lithium Iron Phosphate (LiFePO₄) Nominal Voltage: 51.2 V Nominal Capacity: 150 Ah Usable Energy: Up to 90–100% depending on system configuration Cycle Life: ≥ 6000 cycles at 80% DoD Depth of Discharge (DoD): Up to 95% Electrical Parameters Charge Voltage: Approx. 56–58 V Discharge Cut-off Voltage: Approx. 44–46 V Max Continuous Charge Current: 100 A Max Continuous Discharge Current: 100 A Communication: CAN / RS485 Protection & Safety Integrated Smart BMS Overcharge Protection Over-discharge Protection Overcurrent Protection Short Circuit Protection Over-temperature Protection Mechanical Specifications Mounting Type: Rack-mounted Cooling: Natural convection IP Rating: IP20 Design Life: 10–15 years Environmental Conditions Operating Temperature (Charge): 0°C to 55°C Operating Temperature (Discharge): -20°C to 55°C Storage Temperature: -20°C to 60°C Scalability Parallel Connection: Multiple units supported for expanded capacity Suitable for residential, commercial, and industrial solar systems
